Seeker 24 (MY24/25)
Superhero stuff.
If Marvel decided they needed a new, albeit small-ish, superhero to travel to remote parts of our planet and save the world from a mass extinction, they'd give them one of these. It is front to back spec'd with components designed for adventure: high performance, incredibly durable and, in case the need arises far from home, immediately serviceable.
A superb, lightweight, wide range 1 x 9 system, boasting a 11-46 cassette that gives a whopping, market-topping 418% gear range. The kids could soon get granny in a cape crushing those climbs in far away places. A lightweight but robust aluminium frame and 1 1/8th inch steerer fork to make sure it can absorb those big hits the trails (and curbs) will inevitably throw at you. And a long, low and slack geometry with premium Ritchey controls to give the stability your kid will need to ride them out as well as the bike.(Over and over again).
ASSEMBLY INSTRUCTIONS:
Your bike will arrive carefully packaged and boxed with the front and rear wheel detached. Attach both wheels using the skewers supplied and install the gearing mechanism. The handlebar will be ziptied to the top tube, simply remove the bars and all packaging and attach to the stem. Add the saddle and adjust to the required height. Then simply add the pedals. Please retain your manual.
[Left column]
INSIDE LEG
63CM
FRAME
HAND BRUSHED AL6061, FORGED SLIDING DROP OUTS
FORK
HAND BRUSHED AL6061, FORGED DROPOUTS
STEERER TUBE
AL6061
CRANKS
SAMOX 150MM DIRECT MOUNT, NQF
PEDALS
ER WORKS PLATFORM, CNC'D AL6061, STUDDED, CARTRIDGE BEARING
BOTTOM BRACKET
SAMOX 24MM EXTERNAL CUP, SEALED CARTRIDGE
RIMS
24 X 28H, DOUBLE WALLED AL6061, TUBELESS COMPATIBLE
REAR HUB
ER 4 BEARING CASSETTE FREEHUB, CNC'D AL6061
FRONT HUB
CNC’D 6 BOLT DISC, AL6061, QR SKEWER
CHAIN
BOX 3
CHAINRING
SAMOX BLACK DIRECT MOUNT STEEL 30T
REAR CASSETTE
BOX 3, 11-46T (SILVER)
SHIFTER
BOX 3, MULTI TWIN SHIFTER
*Every effort has been made to ensure accuracy throughout this website. However, Early Rider reserves the right to change prices and bike specifications without prior notice*
CLICK HERE FOR THE USER MANUAL
[Right column]
WEIGHT
9.95KGS W/O PEDALS
DERAILLEUR
BOX 3, P9 CLUTCH EQUIPPED REAR MECH
BRAKES
PROMAX DSK926 HYDRAULIC JR, 160MM ROTORS
LEVERS
PROMAX DSK926 JR
FRONT TYRE
VEE CROWN GEM 24x2.25", 27TPI WB
REAR TYRE
VEE CROWN GEM 24x2.25", 27TPI WB
HEADSET
1 1/8” CARTRIDGE BEARING, CONVENTIONAL
STEM
RITCHEY OS FORGED AL6061, 35MM REACH
BARS
640MM RITCHEY OS DOUBLE BUTTED AL6061, 18MM RISE
GRIPS
ER LOCK ON KRATON 115MM
SEAT POST
RITCHEY AL6061, 27.2MM x 350MM
SADDLE
SDG FLY JR, BLACK
SEAT CLAMP
ER QR, 31.8MM
[Table]
| STANDOVER HEIGHT | 63CM |
| FRAME | HAND BRUSHED AL6061, FORGED SLIDING DROP OUTS |
| FORK | HAND BRUSHED AL6061, FORGED DROP OUTS |
| STEERER | TUBE AL6061 |
| CRANKS | SAMOX 150MM DIRECT MOUNT, NQF |
| PEDALS | ER WORKS PLATFORM, CNC'D AL6061, STUDDED, CARTRIDGE BEARING |
| BOTTOM BRACKET | SAMOX 24MM EXTERNAL CUP, SEALED CARTRIDGE |
| RIMS | 24 X 28H, DOUBLE WALLED AL6061, TUBELESS COMPATIBLE |
| REAR HUB | ER 4 BEARING CASSETTE FREEHUB, CNC'D AL6061 |
| FRONT HUB | CNC’D 6 BOLT DISC, AL6061, QR SKEWER |
| AXLES | AL6061 |
| CHAIN | BOX 3 |
| CHAINRING |
DIRECT MOUNT, NARROW WIDE 30T, STEEL |
| WEIGHT | 9.95KGS W/O PEDALS |
| REAR CASSETTE | BOX 3, 11-46T (SILVER) |
| BRAKES | PROMAX DSK926 HYDRAULIC JR, 160MM ROTORS |
| LEVERS | PROMAX DSK926 JR |
| FRONT TYRE | VEE CROWN GEM 24x2.25", 27TPI WB |
| REAR TYRE | VEE CROWN GEM 24x2.25", 27TPI WB |
| HEADSET | 1 1/8” CARTRIDGE BEARING, CONVENTIONAL |
| STEM | RITCHEY OS FORGED AL6061, 35MM REACH |
| BARS | 640MM RITCHEY OS DOUBLE BUTTED AL6061, 18MM RISE |
| GRIPS | ER LOCK ON KRATON 115MM |
| SEAT POST | RITCHEY AL6061, 27.2MM x 350MM |
| SADDLE | SDG FLY JR, BLACK |
| SEAT CLAMP | ER QR, 31.8MM |
| DERAILLEUR | BOX 3, P9 CLUTCH EQUIPPED REAR MECH |
| SPEC NOTICE | Every effort has been made to ensure accuracy throughout this website. However, Early Rider reserves the right to change prices and bike specifications without prior notice |
[Table spec]
| A | Wheelbase | 980mm |
| B | Head Angle | 68° |
| C | Seat Tube Length | 320mm |
| D | Chainstay Length | 390mm |
| E | Seat Tube Angle | 73° |
| F | Standover Height | 625mm |
| G | Top Tube Length | 513mm |
| H | Head Tube Length |
92mm |
| I | Stack |
481mm |
| J | Reach |
366mm |
| K | Fork Length | 400mm |
Original: $953.20
-70%$953.20
$285.96
